Modular adapter system for the quick attachment/detachment of the thermal imaging attachment. The system is bulletproof and allows for a repeatable connection of the modules. Available for all common lens diameters and thread connections.
Mounting
The clamp adapter is adjusted to the riflescope and fixed with the quick-release lever. The connector (please order separately, not included in the delivery) has 4 locking pins and is connected to the clamp adapter via a bayonet mount. A spacer ring (usually included with the secondary optics) is then used to connect the connector to the attachment device.
Modulares Adaptersystem für das schnelle Auf/Abnehmen des Wärmebild-Vorsatzgerätes. Das System ist schussfest und ermöglicht eine wiederholgenaue Verbindung der Module. Erhältlich für alle gängigen Objektiv-Durchmesser und Gewindeanschlüsse.
Montage
Der Klemmadapter wird am Zielfernrohr justiert und über den Schnellverschlusshebel fixiert. Der Connector (bitte gesondert bestellen, nicht im Lieferumfang enthalten) besitzt 4 Verriegelungswarzen und wird über einen Bajonettverschluss mit dem Klemmadapter verbunden. Über einen Zwischenring (i.d.R. im Lieferumfang der Sekundäroptik) wird dann der Connector mit dem Vorsatzgerät verbunden.
