Sensor CMOS HD 1280x720
Wavelength of the IR emitter 940nm
IR optical power, up to 700mW
Detection range 500m
Objective lens F50/1.0
Field of view 6.3x4.7°
Recommended magnification of the day sight 2 8x
Screen AMOLED
Resolution 1746x1000 pixels
Video recorder
Video / photo resolution 640x480 pixels
Video / photo format .mp4 / .jpg
Built-in storage 16GB
Wi-Fi standard 802.11 b/g
Frequency 2.4GHz
Bluetooth wireless protocol BLE 4.2
Wireless standard IEEE 802.15.1
Frequency 2.4GHz
Environmental features
Protection class, IP code (IEC60529) IP?7
Operating temperature range -25 +50°C
Connections and compatibilities
Remote control: Pulsar BT (included)
Supported application: Stream Vision 1, Stream Vision 2
Power supply
Output voltage 3.0 4.2V
Battery type
Li-Ion Battery Pack IPS7
Battery type 6400mAh
Operating time up to 9 hours
External power supply Micro USB type B (5V)
Weight & size
Housing material Magnesium
Dimensions 155x136x77mm
Weight 830g
Sensor CMOS HD 1280x720
Wellenlänge des IR-Strahlers 940nm
IR Optische Leistung, bis zu 700mW
Erfassungsbereich 500m
Objektivlinse F50/1.0
Sichtfeld 6.3x4.7°
Empfohlene Vergrößerung des Tagesvisiers 2 8fach
Bildschirm AMOLED
Auflösung 1746x1000Pixel
Videorecorder
Video- / Fotoauflösung 640x480Pixel
Video- / Fotoformat .mp4 / .jpg
Eingebauter Speicher 16GB
Wi-Fi Standard 802,11 b/g
Frequenz 2.4GHz
Bluetooth Wireless Protocol BLE 4.2
Wireless Standard IEEE 802.15.1
Frequenz 2.4GHz
Umweltmerkmale
Schutzart, IP-Code (IEC60529) IP?7
Betriebstemperaturbereich -25 +50°C
Verbindungen und Kompatibilitäten
Remote control : Pulsar BT (included)
Unterstützte Applikation : Stream Vision 1, Stream Vision 2
Netzteil
Ausgangsspannung 3.0 4.2V
Batterietyp
Li-Ion Battery Pack IPS7
Batterietyp 6400mAh
Betriebsdauer bis zu 9Stunden
Externe Stromversorgung Micro USB type B (5V)
Gewicht & Größe
Gehäusematerial Magnesium
Abmessungen 155x136x77mm
Gewicht 830g
