At the Peak of Perfection.

In the EL Range, the best of optical performance and ergonomics is combined. Crystal-clear images with precise distance and angle measurement, along with the perfectly balanced weight for steady handling, speak for this masterful binocular. With the FieldPro package, the quick switch between strap and accessories and the new, clearly defined measurement button are now also among the advantages of the EL Range.

EL Range 8x42 W B

Precision can be this versatile. The EL Range 8x42 binocular is suitable for numerous situations up to twilight. Its large field of view and large exit pupil ensure maximum observation comfort. With the new FieldPro package, the EL Range 8x42 also impresses with its advanced strap connection, integrated objective and eyepiece protective caps, and the new, distinctive measurement button for even more precise operation.

Included

Comfort carrying strap Pro with pockets for spare battery made of new, improved material for increased carrying comfort, Field Bag Pro, eyepiece protective cap, objective protective cap

Technical Data:

• Magnification: 8x


• Effective objective diameter (mm): 42


• Exit pupil diameter (mm): 5.3


• Exit pupil distance (mm) (eye relief): 19.2


• Field of view (m/1000 m): 137


• Field of view (degrees): 7.8


• Field of view for eyeglass wearers (degrees): 7.8


• Eye-side field of view (degrees): 61


• Shortest focusing distance (m): 5


• Diopter adjustment (dpt): -7/+5


• Light transmission (%): 91


• Pupil distance (mm): 56 - 74


• Dusk number according to DIN 58388: 18.3


• Length approx. (mm)*: 166


• Width approx. (mm)**: 137


• Height approx. (mm)**: 81


• Weight approx. without battery (g): 895


• Operating temperature (mechanical / electronic): -25 °C/+55 °C / -10 °C/+55 °C


• * Value with eyecup lowered: -


• ** Dimensions at 64 mm pupil distance: -


• Measurement range (m): 30 - 1,375


• Measurement accuracy (m): ± 1


• Measurement duration (sec): ≤ 1


• Angle measurement (degrees): ± 90


• Laser: Class 1 EN/FDA


• Switching: Yard / Meter


• Battery: CR2


• Lifetime: 1,000 measurements
