Thermal Module
Image sensor: VOx Uncooled Focal Plane Arrays
Resolution: 640 x 512
Frame rate: 50Hz
Pixel pitch: 12µm
NETD: less than 20 mK (@25°C), F#=1.0
Focal length: 50 mm
Detection range: 2600 m
Field of view: 8.78° x 7.03° / 15.36 m x 12.29 m
Aperture: F1.0
Magnification: 1
Minimum focus distance: 10 m
Monitor: 0.39 inch, OLED, 1024 × 768
Palettes: Black Hot, White Hot, Red Hot, Fusion
FFC (Flat Field Correction): Automatic, manual, external correction
Image brightness adjustment: Yes
Display brightness adjustment: Yes
Contrast adjustment: Cold, Warm
System Function
Storage: Built-in storage module (16 GB)
Video recording: integrated video recording
Snapshot: integrated image capture
Reticle: No
Wi-Fi: Yes
Hot Track: Yes
Standby mode: Yes
Recoil-activated video recording: Yes
Audio recording: Yes
Maximum recoil: 1000g / 0,...
(Show description in original language)
Thermal Module
Bildsensor: VOx Uncooled Focal Plane Arrays
Auflösung: 640 x 512
Bildfrequenz: 50Hz
Pixelintervall: 12µm
NETD: weniger als 20 mK (@25°C), F#=1,0
Brennweite: 50 mm
Erkennungsreichweite: 2600 m
Sichtfeld: 8.78° x 7.03° / 15.36 m x 12.29 m
Blende: F1.0
Vergrößerung: 1
minimale Fokusdistanz: 10 m
Monitor: 0.39 inch, OLED, 1024 × 768
Palettes: Black Hot, White Hot, Red Hot, Fusion
FFC (Flat Field Correction): Automatische, manuelle, externe Korrektur
Anpassung der Bildhelligkeit: Ja
Anpassung der Displayhelligkeit: Ja
Tonwertanpassung: Kalt, Warm
System Function
Speicher: Eingebautes Speichermodul (16 GB)
Video-Aufnahme: integrierte Videoaufnahme
Schnappschuss: integrierte Bildaufnahme
Fadenkreuz: Nein
Wi-Fi: Ja
Hot Track: Ja
Standby Modus: Ja
Rückstoß-Aktivierende Videoaufnahme: Ja
Audio-Aufnahme: Ja
Maximaler Rückstoß: 1000g / 0,...
