Hikmicro Lynx LH 25 3.0

HIKMICRO Monocular Lynx LH25 3.0 – Thermal Imaging Monocular for Long Distances



The HIKMICRO Lynx LH25 3.0 sets new standards in its class. With a 384 × 288 pixel VOx thermal imaging sensor, a fast 25 mm F1.0 lens, and a 2.5× base magnification, it delivers razor-sharp images with the highest detail accuracy. The field of view of 10.5° (18.4 m at 100 m) and the impressive detection range of up to 1200 m make this compact device ideal for observations in open landscapes and professional applications.

The 0.49″ AMOLED display with 1920 × 1080 pixels ensures crystal-clear representation. With the HIKMICRO Shutterless Image System (HSIS), mechanical calibration is eliminated – observations are therefore completely silent and uninterrupted. Additionally, the algorithms Image Pro 3.0 and Zoom Pro automatically optimize image sharpness and contrast.

With its robust, IP67-certified housing, a weight of only 328.5 g, and a runtime of up to 5 hours, the LH25 3.0 is the ideal companion for hunters, outdoor adventurers, and professional users looking for a compact, powerful thermal imaging device with great range.



Main Features:

• 384 × 288 @ 12 μm VOx thermal imaging sensor for excellent detail reproduction
• NETD < 15 mK for clear images even in adverse weather conditions
• 25 mm F1.0 lens with up to 1200 m detection range
• 2.5× base magnification for precise long-distance viewing
• 0.49″ AMOLED display with 1920 × 1080 pixels
• HIKMICRO Shutterless Image System (HSIS) for silent calibration
• Image Pro 3.0 & Zoom Pro for optimized image quality
• Internal 64 GB storage for photo and video recordings
• Up to 5 hours runtime with replaceable 18650 battery
• Compact, IP67-protected design, only 328.5 g light



Technical Specifications:

Thermal Imaging Module:
• Sensor: VOx Uncooled Focal Plane Arrays
• Resolution: 384 × 288 pixels
• Frame Rate: 50 Hz
• Pixel Pitch: 12 μm
• Spectral Range: 8 – 14 μm
• NETD: < 15 mK (@ 25 °C, F#=1.0)
• Lens: 25 mm, F1.0, focus via focus wheel
• Minimum Focus Distance: 3 m
• Magnification: 2.5× – 20× (8× digital)
• Field of View: 10.5° × 6.4° (18.4 × 11.2 m @ 100 m)
• Detection Range: 1200 m

Display & Functions:
• Display: 0.49″ AMOLED, 1920 × 1080 pixels
• Palettes: Black Hot, White Hot, Red Hot, Fusion, Red & Green Monochrome
• Image Optimization: Image Pro 3.0, Zoom Pro, HSIS
• Functions: PIP, Hot Track, Distance Measurement, Video & Audio Recording, Snapshot
• Storage: Internal 64 GB EMMC storage
• Connectivity: 2.4 / 5 GHz WiFi hotspot

Battery & Runtime:
• Battery: Replaceable 18650 Li-Ion battery
• Operating Time: ≥ 5 h (at 25 °C, WiFi on) / ≥ 4.5 h (at −20 °C, WiFi on)
• Charging: Type-C connection (5 V DC, 2 A), supports external power supply

Housing & Protection:
• Protection Class: IP67 (dust and waterproof)
• Operating Temperature: −30 °C to +45 °C
• Dimensions: 158.4 × 53.6 × 49.5 mm (≈ 15.8 × 5.4 × 5.0 cm)
• Weight: 328.5 g (including battery)
