Thermtec Ares 360 LRF innovative thermal sight with laser rangefinder and motion sensor, ideal for detection, recognition and
Since then, it has a resolution of 388 × 288, pixel pitch of 12 um, NETD ≥35 mK, OLED screen, smart rangefinder, motion sensor, with a 60 mm lens offering 3000 meters of detection and 1500 meters of identification for a human.
Laser rangefinder with readings up to 1000 meters.
Optical magnification 1.8X/5.5X
Resolution 384*288
pixel pitch 12µm
NETD ≤25mk
Spectral range 8-14µm
Frame rate 50HZ
Objective lens 20/60mm, F/1.0
Field of view 13.1°x9.8% 4.4*x3.3
Magnification 1.8X/5.5X
Digital zoom 1.0-5.0X smooth &rapid zoom
Eye relief 50mm
Exit pupil 6mm
Diopter -5 ~ +5D
Click range, m @100 m (H/V) 3,6m/3,6m
Reticle 7
Rectile color Black and white
Display type AMOLED
Resolution, pixel 1024x768
Display size 0.39 inch
Color palette 6
Max. recoil power on rifled weapon 6000J
Mounting brackets on weapon Standard 30mm rings
RAV Yes
Auto zeroing Yes
Manual zeroing Yes
Zeroing profiles 5
Picture-in-picture Yes
Laserranging 1000m
Image calibration Via lens cover
Photo/video playback Yes
Built-in memory 16GB
Type C Data transfer
Wi-Fi Yes
Battery type Replaceable, 18650 or 18500 battery
Built-in Battery 5000mAh, rechargeable
Battery life 12h
Operating temperature -20℃-+50℃
IP rating IP67
Weight, g 1250
Dimension,mm 438(L)x84(W)x105(H)
External cable USB data cable
Other accessories 2x standard 30mm rings, eyeshade and etc.
