Magnification: 5-50x
Objective diameter, mm: 56
reticle: DLS-2
Illuminated reticle: Yes
Field of view (degrees): 4.04-0.41
Field of view at 100 m (m): 7.1-0.7
Eye relief diameter, mm: 7.2-1.1
Eye distance, mm: 89-100
Water resistance: 0.3kg/cm2
Weight, g: 1100
Length, mm: 335
Adjustment per click at 100 m: 0.1 MIL (1 cm @ 100m)
Max elevation / windage adjustment: 100/50 MOA
Main tube: 34mm (1 piece)
Shock resistance: 6500 J
Operating temperature: +71°C | –20°C
Gas filling: Nitrogen
Parallax adjustment: Side focus (10 m - 8)
Position of reticle: Second focal plane (SFP)
Note: ZeroLock
(Show description in original language)
Vergrößerung: 5-50x
Objektivdurchmesser, mm: 56
Absehen: DLS-2
Leuchtabsehen: Ja
Sichtfeld (Grad): 4,04-0,41
Sehfeld auf 100 m (m): 7,1-0,7
Austrittspupillendurchmesser, mm: 7,2-1,1
Augenabstand, mm: 89-100
Wasserdichtigkeit: 0,3kg/cm2
Gewicht, g: 1100
Länge, mm: 335
Verstellung pro Klick auf 100 m: 0,1 MIL (1 cm @ 100m)
Maximale Höhen- / Seiten-Verstellung: 100/50 MOA
Mittelrohr: 34mm (1 Stück)
Stoßfestigkeit: 6500 J
Arbeitstemperatur: +71°C | –20°C
Gasfüllung: Stickstoff
Paralaxe-Einstellung: Side focus (10 m - 8)
Position des Absehens: Zweite Bildebene (SFP)
Bemerkung: ZeroLock
