Technical data:
Objective lens F50/1.2 Field of view (HxV),
Degrees / m @ 100m 5.6х4.2 / 9.7x7.3
Sensor type uncooled
Main sensor: 384x288 pixels
Pixel pitch, 17 µm
Magnification in monocular mode 5x,
Magnification in attachment mode 0
Recommended magnification of optics, 2 – 5x
Screen type AMOLED
Frame rate, 50 Hz
Resolution, 640x480 pixels
Observation distance, 1800m
Protection class, IP code (IEC60529) IPХ7
Operating temperature range, -25 – +50°С
Dimensions, 310x71x67 mm (with Pulsar 5x30 Monocular)
Weight, 550g
Power supply output voltage, 5 – 7.2V
Battery type 2xCR123A, 650 mAh
Operating time on battery (at t = 22 ° C) 4h
External power supply, 5V
(Mostra descrizione nella lingua originale)
Technische Daten:
Objektivlinse F50/1.2 Sichtfeld (HxV),
Grad / m @ 100m 5.6х4.2 / 9.7x7.3
Sensor Typ uncooled
Main Sensor: 384x288 Pixel
Pixelabstand, 17 µm
Vergrößerung im Monokularmodus 5x,
Vergrößerung im Vorsatzmodus 0
Empfohlene Vergrößerung der Optik, 2 – 5x
Bildschirm Typ AMOLED
Bildfrequenz, 50 Hz
Auflösung, 640x480 Pixel
Beobachtungsdistanz, 1800m
Schutzart, IP-Code (IEC60529) IPХ7
Betriebstemperaturbereich, -25 – +50°С
Abmessungen, 310x71x67 mm (mit Pulsar 5x30 Monocular)
Gewicht, 550g
Netzteil Ausgangsspannung, 5 – 7.2V
Batterietyp 2xCR123A, 650 mAh
Betriebsdauer am Akku (bei t = 22 ° C) 4h
Externe Stromversorgung, 5V
