Guide sensmart TN650MS

The TN650MS from Guide Sensmart is a powerful multispectral device that combines digital day and night vision with thermal imaging technology and features an integrated laser rangefinder.With the TN650MS, Guide Sensmart presents an all-in-one device that can be used with the comfort of a classic binocular. Thanks to intelligent sensor fusion, the digitally and thermally generated data can be combined. The integrated laser rangefinder provides the data for the perfect shot.

The Sensors
The large, powerful 12-µm thermal sensor has a resolution of 640×512 px and an NEDT value of 15 mK, allowing it to detect the smallest temperature differences. Its detection range is 2,600 m and the field of view is 22x17 m at 100 m. The digital 4K CMOS sensor has a resolution of 3,840×2,160 px and delivers stable image quality in all lighting conditions. It achieves a field of view of 10x6 m at 100 m.

The Display
The 0.49-inch AMOLED color display with a resolution of 1,440×1,080 px allows for comfortable viewing of the algorithmically optimized images. The menu control is logically structured and intuitively designed. Depending on personal preferences and situations, 7 color palettes can be selected: Hot White, Hot Black, Hot Red, Hot Green, Hot Blue, Iron Red, and Sepia. Observations can be documented as photos or videos with sound on the integrated 256 GB storage.

The Device with LRF
Integrated into the TN650MS thermal binocular is a laser rangefinder with a range of 1,500 m, as well as GPS and a digital compass. The silent button layout is designed to be minimalist with its multifunctional knobs and individually customizable buttons, making operation intuitive. The menu navigation on the user interface is also simple, with selection made by scrolling and confirmation by clicking. The binocular is powered by a built-in battery and a replaceable and rechargeable 18650 battery, with a runtime of up to 5 hours. The housing is protected according to IP67 standards. Data transfer and updates are done via Wi-Fi and the Guide app or through the USB interface with a PC.

Scope of Delivery

DeviceBag2 x 18650 batteryUSB A to C cable5V/2A power supplyEyeshadeHand strapNeck strapCleaning clothQuick guideWarranty card

Technical Data

Type: Thermal binocularThermal sensor: uncooled VOx infrared detector, 8 to 14 μm, 640×512@15μm, NETD: 15 mKDigital sensor: CMOS, 3,840×2,160@2μmFrame rate: 50 HzLens: thermal: 50 mm, F1.0; Digital: 70 mm, F1.8Field of view thermal: 14×9 m at 100 m / 8.2×4.9°Field of view digital: 10x6 m at 100 m / 5.9x3.5°Magnification: thermal: 3.9x–31.2x; digital: 5.4x–43.2xDetection range: thermal: 2,600 m; digital: 1,300 mDisplay: 0.49" inch AMOLED 1,440×1,080 pxColor palettes: Hot White, Hot Black, Hot Red, Hot Green, Hot Blue, Iron Red, and SepiaEyepiece: eye relief: 20 mm; diopters: ±6 dpt; interpupillary distance: 58–72 mm; zoom: 13.8xRange of laser rangefinder: 1,500 mWi-Fi: 2.4G, 5GInterfaces: USB-C (supports charging), BluetoothRecording function: photo, video (including sound)Storage capacity: 256 GBCompassGyroscope
Battery: built-in battery and replaceable 18650 batteryOperating time: 5 hOperating temperature: -20 °C to 50 °CProtection: IP67Size: 235x134x63 mmWeight: 1,110 g
