EOTECH 552.A65

Available from stock with us.

The legendary EOTECH HWS 552 is the classic among holographic sights and has been the first widely used military version in service since 2001. These high-quality and robust optics use a laser to create a holographic, 3-dimensional reticle made up of multiple points - a technique that, as the manufacturer states, originates from military aviation.

The models of the 5xx series are on par with the younger siblings of the XPS & EXPS series in their performance data, with the primary difference being the use of AA cells, which gives rise to the characteristic long nose of the sight. The height of the optical axis is 38mm, just like the XPS models. Alkaline, lithium, and rechargeable AA cells with 1.5V can be used - the lifespan of the various battery types is more than twice as long as that of the sister models with a single CR123 cell.

The Model 552 features 20 brightness levels for daytime use and 10 additional NV-compatible brightness levels for nighttime use and with night vision devices. The controls are located on the back of this model, which means that a magnification module requires more distance from the sight.

The 5x series consists of the following models:

Eotech HWS 512

- Standard mount
- No NV mode
- Controls at the back

Eotech HWS 552 - the classic

- Standard mount
- NV mode
- Controls at the back

Eotech HWS 518

- QD mount
- No NV mode
- Controls on the side

Eotech HWS 558

- QD mount
- NV mode
- Controls on the side

Product details:

Eotech HWS 552
Standard Picatinny mount
Reticle A65

- 65 MOA circle with 1 MOA dot

Battery: 2x AA 1.5V

- Lithium, alkaline, or rechargeable

Brightness levels

- 20 daylight
- 10 NV

Battery life at level 12

- approx. 2,500 hours with lithium
- approx. 2,200 hours with alkaline

Reticle adjustment 0.5 MOA (approx. 14mm/100m) per click
Operating temperature from -40°C to 60°C
Waterproof up to 10m
Dimensions: 142.2x50.8x63.5mm
Weight: 326g

The manual in German can be found here.

Note on products from EOTECH:

The packaging of the products is opened upon arrival in Germany to verify the serial numbers with the manufacturer's specifications, meaning that any "seal stickers" may no longer be intact. The battery is already installed from the factory. Due to these work steps, it is possible that mounting traces are visible. This is completely normal. This is NOT B-grade merchandise!

EOTECH produces professional optics that are trusted by leading professionals worldwide. Unmatched speed, accuracy, and reliability are cornerstones of this legendary brand. Since 1996, EOTECH Holographic Weapon Sights (HWS) have been designed, developed, and manufactured in the USA. In 2016, EOTECH expanded its optics line with the introduction of the Vudu line of premium magnifying optics, designed for the most demanding users. The rigorous standards require a continuous focus on product quality, not quantity, to ensure that the highest specifications are not only met but exceeded. When there is no room for error, compromises are not an option. Exactly the right league, where EOTECH feels at home.

Warning: This product contains very small and/or button batteries.

Improper handling of batteries can lead to significant injuries or even death within just 2 hours, especially in young children (e.g., chemical burns and possible perforation of the trachea). If you suspect that a battery has been swallowed, please seek medical attention immediately. Keep batteries out of reach of children.
Dispose of empty or defective batteries immediately in accordance with local disposal regulations.
General usage note: Always insert batteries correctly (+/-), risk of injury from fire, explosions, or leaks, do not disassemble, charge, crush, expose to fire or high temperatures.

Note: Battery and Electrical Act (§ 18 BattG in conjunction with § 10 para. 1 ElektroG)
