EOTECH HWS EXPS2-2

Available from stock with us.

The EXPS 2-0 from EOTECH is among the best holographic sights currently available. For those who do not want to compromise, EOTECH offers the reflex sight HWS EXPS2-2. The EXPS 2-2 is also among the best holographic sights currently available. In terms of workmanship, quality, and performance, this small high-end reflex sight is truly worth its price. The nearly indestructible housing is additionally protected by a protective hood made of hard-anodized, matte black aluminum. With the integrated quick-release mount, you can quickly and, above all, repeatably attach the sight to your weapon. All controls or the battery compartment are accessible from the side.

But not only is the workmanship at EOTECH absolutely top-notch - the holographic reticle, consisting of hundreds of small dots, ensures high sharpness and low glare. The 2-dot reticle is specifically aligned with hold points for the caliber .223. In addition to the 1 MOA center dot, there is another 1 MOA dot below as a hold point for ~460m. The 68 MOA large circle primarily serves for quick target acquisition during hunting or dynamic disciplines (30 cm at 50m). This ballistic reticle was developed for 5.56 NATO/.223 cal with 62 g M855 FMJ at approximately 2,680 fps with a 14.5-inch barrel. When using different ammunition or barrel lengths, the reticle points may vary slightly.

The brightness can be adjusted in a total of 20 levels, ensuring perfect visibility in any daylight situation.

In short - simply brilliant and definitely worth the money!

What are the differences between the variants?

XPS - the Base

- no quick-release
- controls are located at the back (towards the shooter)
- height of the optical axis approx. 38mm

EXPS - the Tactical

- quick-release
- controls are located on the side (left)
- height of the optical axis approx. 45mm

2 - the Civilian

- no night vision mode

3 - the Operator

- night vision mode

What are the different reticles?

-0

- the standard reticle
- 1 MOA dot with 65 MOA circle

-1

- 1 MOA dot, ONLY the dot

-2

- 1 MOA dot with 65 MOA circle
- another 1 MOA dot below the first, for 500yds (at 50/200yds zero)

-4

- 1 MOA dot with 65 MOA circle
- three additional 1 MOA dots below the first, for 400, 500 & 600yds (at 50/200yds zero)

This results in, for example:

XPS2-0

- without quick-mount
- rear controls
- without night vision mode
- circle-dot reticle

EXPS3-4

- quick-mount
- side controls
- with night vision mode
- circle-dot reticle with 3 additional hold points

The night vision mode adjusts the illuminated reticle down so that there is no glare from night vision devices (NVG-compatible).

Reticle:

Highlights EXPS 2-2:

- 1x magnification
- Parallax-free
- Illuminated reticle: yes, holographic
- Ballistic hold points for caliber .223 (up to 500m)

- 2 MOA red dots (center ~45-180m + 1 hold point ~460m)
- 68 MOA ring (30cm / 100m)

- Unique illuminated ring structure made of many small dots, resulting in low dispersion
- 20 brightness levels for very fine adjustment in daylight
- Programmable shutdown (automatic)
- including Picatinny / Weaver quick-release mount
- Waterproof up to 3m diving depth
- Fog-proof due to hermetic sealing of the housing
- Protective hood made of hard-anodized, matte black aluminum
- Shock-resistant housing made from a block of aircraft aluminum
- Remaining energy warning

Scope of delivery:

- HWS EXPS2
- Quick start guide
- CR123 battery

The manual in German can be found here.

Note on products from EOTECH:

The packaging of the products will be checked upon arrival in
Deutschland opened to compare the serial numbers with the manufacturer information, i.e. possibly "seal stickers" are no longer intact. The battery is already factory-installed. Due to these work steps, it may be possible that assembly traces are visible. This is completely normal. This is NOT B-goods!



Technical Data EXPS2-2

Magnification:
1x


Eye relief in mm:
unlimited


Reticle:
2 x 1 MOA dots + 68 MOA ring


Illuminated reticle:
yes (red)


Brightness levels:
20x daylight (no night vision)


Reticle adjustment / click:
0.5 MOA (100 m)


Max. reticle adjustment height:
+- 40 MOA


Max. reticle adjustment side:
+- 40 MOA


Temperature range:
- 40°C to + 60°C


Size in mm:
91 x 60 x 71 mm (l x w x h)


Weight in g:
317 g


Battery:
yes, CR123

EOTECH produces professional optics that are trusted by leading professionals worldwide. Unmatched speed, accuracy, and reliability are cornerstones of this legendary brand. Since 1996, EOTECH Holographic Weapon Sights (HWS) have been designed, developed, and manufactured in the USA. In 2016, EOTECH expanded its optics series with the introduction of the Vudu line of premium magnified optics designed for the most demanding users. The rigorous standards require a continuous focus on product quality, not quantity, to ensure that the highest specifications are not only met but exceeded. When there is no room for error, compromises are not an option. Exactly the right league, where EOTECH feels at home.
