EOTECH XPS3-DCR

Available from stock with us.

The XPS-DCR from EOTECH is qualitatively among the best holographic sights currently available. In terms of workmanship, quality, and performance, this high-end reflex sight is truly worth its price. The nearly indestructible housing is additionally protected by a protective hood made of hard-anodized, matte black aluminum. With the integrated quick-release mount, you can quickly and, above all, repeatably attach the sight to your weapon. The battery compartment is accessible from the side, and the controls are located on the back, facing the shooter. The compact design of the system also takes up very little space on your Picatinny rail; ~67 mm is more than sufficient here.

Differences to the EXPS model: Brightness control at the back of the device (on EXPS it is on the side, making operation easier in the shooting position), On EXPS: Quick-mount system - XPS with Torx screw for fixation. The height of the optical axis is approximately 38mm for the 55x and XPS models, and about 45mm for the EXPS models.

DCR stands for "Danger Close Reticle" and addresses the fact that with classic 50/200 zero (50 yards to 200 yards), targets at very short distances are missed when the normal hold point is used. Therefore, the target circle is cut off at the top and bottom, and below the classic 1 MOA point, there is a target spike set for 7 yards. This allows for precise shooting at very short distances.

In short - simply brilliant and definitely worth the money!

What are the differences between the variants?

XPS - the base

- no quick release
- controls are located at the back (towards the shooter)
- height of the optical axis approximately 38mm

EXPS - the tactical

- quick release
- controls are located on the side (left)
- height of the optical axis approximately 45mm

2 - the civilian

- no night vision mode

3 - the operator

- night vision mode

What are the different reticles?

-0

- the standard reticle
- 1 MOA dot with 65 MOA circle

-1

- 1 MOA dot, ONLY the dot

-2

- 1 MOA dot with 65 MOA circle
- another 1 MOA dot below the first, for 500yds (at 50/200yds zero)

-4

- 1 MOA dot with 65 MOA circle
- three additional 1 MOA dots below the first, for 400, 500 & 600yds (at 50/200yds zero)

This results in, for example:

XPS2-0

- without quick mount
- rear controls
- without night vision mode
- circle-dot reticle

EXPS3-4

- quick mount
- side controls
- with night vision mode
- circle-dot reticle with 3 additional hold points

The night vision mode adjusts the illuminated reticle down so that there is no blooming from night vision devices (NVG-compatible).

Reticle: DCR (Danger Close Reticle)

Highlights:

- 1x magnification
- Parallax-free
- Color: Black
- Illuminated reticle: yes, holographic
- Brilliant DCR reticle suitable for quick & precise target acquisition

- 1 MOA red center
- cut-off 65 MOA ring (188.5cm / 100m)
- target spike for very short distances

- Unique illuminated ring structure made of many small dots, resulting in low dispersion
- 20 brightness levels for very fine adjustment in daylight
- Not suitable for night vision devices
- including Picatinny / Weaver quick-release mount
- Waterproof up to 3m diving depth
- Fog-free due to hermetic sealing of the housing
- Protective hood made of hard-anodized, matte black aluminum
- Shock-resistant housing made from a block of aircraft aluminum
- Low battery warning

Scope of delivery:

- EOTech XPS-DCR
- Quick start guide
- no battery

The manual in German can be found here

Note on products from EOTECH:

The packaging of the
Products are opened upon arrival in Germany to verify the serial numbers with the manufacturer's specifications, meaning any "seal stickers" may no longer be intact. The battery is already installed from the factory. Due to these procedures, it may be possible that assembly marks are visible. This is completely normal. This is NOT B-grade merchandise!



Technical Data:

Magnification:
1x


Eye Relief in mm:
unlimited


reticle:
65 MOA ring + aiming dot


Illuminated Reticle:
yes (red)


Brightness Levels:
20x


reticle adjustment / click:
0.5 MOA (100 m)


Max. Reticle Adjustment Elevation:
+- 40 MOA


Max. Reticle Adjustment Windage:
+- 40 MOA


Temperature Range:
- 40°C to + 60°C


Size in mm:
95 x 61 x 61 mm (l x w x h)


Weight in g:
250 g


Battery:
yes, CR123
