PIXFRA Taurus T650 LRF – Thermal Imaging Attachment for Medium to Long Distances

The PIXFRA Taurus T650 LRF is the most powerful attachment in the Taurus series. It is aimed at hunters who rely on long distances and expect image sharpness, range, and precise distance measurement in a compact system. In the field, in large clearings, or while sitting, this model showcases its strengths.

The VOx sensor with 640×512 pixels, 12 µm pitch, and a sensitivity of <18 mK NETD delivers a very finely resolved, stable image. In combination with the 50 mm f1.0 lens, the T650 LRF achieves a detection distance of up to 2600 m. Game can be recognized early and accurately identified, even with small temperature differences.

The field of view of 15.4 × 12.3 m at 100 m is intentionally narrower than that of shorter models. This allows details at a distance to be displayed more clearly. The attachment is designed for use on target optics up to 10x, providing a clean combination of range and precision.

The Sub-Pixel-Zeroing technology ensures a stable point of impact with a click value of 0.9 cm at 100 m. The M52×0.75 thread is compatible with common adapters. The shock resistance of up to 6000 Joules underscores its claim as a fully hunting-capable attachment.

The integrated laser rangefinder measures precisely up to 1000 m and remains invisible to game. Especially at greater distances, it provides reliable distance information and sensibly complements the high optical range.

The display is provided by an OLED screen with 1920×1080 pixels. The device is operated quietly via the 3-button layout and the ergonomic focus dial or via Bluetooth remote control with a magnetic holder. The PIPS 2.0 firmware ensures clean edges, reduced image jitter, and improved zoom. The AAIC image calibration stabilizes the image automatically.

Six color palettes and hotspot tracking support the quick detection of heat sources. The magnesium alloy housing is dust and waterproof according to IP67 and operates reliably from -30 °C to +55 °C.

A replaceable 18650 battery provides up to 6 hours of runtime. For recordings, 32 GB of internal storage is available. Additionally, the T650 LRF allows for a stable WLAN live stream to a smartphone or tablet.

Technology and Equipment for Long Distances

Sensor: VOx 640×512, 12 µm, <18 mK NETD
Lens: 50 mm f1.0, detection distance up to 2600 m
Laser Rangefinder: integrated, up to 1000 m
Field of View: 15.4 × 12.3 m at 100 m
Display: OLED 1920×1080
Zeroing: Sub-Pixel-Zeroing, 0.9 cm click value at 100 m
Mounting Thread: M52×0.75
Firmware: PIPS 2.0 with AI-optimized image calibration (AAIC)
Color Palettes: White-hot, Black-hot, Rainbow, Red-hot, Green-hot, Sepia
Storage: 32 GB internal, photo and video recording
Connectivity: WLAN live stream, Bluetooth remote control
Robustness: IP67, shockproof up to 6000 Joules
Battery Life: up to 6 hours per battery
Dimensions/Weight: 139 × 102 × 73 mm / 580 g

Scope of Delivery

PIXFRA Taurus thermal imaging attachment
2 × 18650 battery
Charging dock for 2 × 18650 battery
USB-C cable
Bluetooth remote control with magnetic holder
Storage case
Carrying strap
5 × heat pads for zeroing
Eyepiece protection cap
Lens cleaning cloth
Velcro strap
Mounting key
Quick start guide
Legal notices and safety information
Warranty card
