Element Optics Helix HD Compact 2-12×42

The HELIX HD COMPACT 2-12×42 from Element Optics is a versatile riflescope that features an HD glass optical system and the illuminated RAPTR-1F reticle for clear and precise target acquisition. It offers a wide magnification range, is compact and lightweight, and is robust thanks to its aluminum construction. It is waterproof, shockproof, and comes with sunshade and lens caps. Perfect for hunters and sport shooters.
Features

Optical system with 6x zoom
30 mm main tube
Ultra-compact, lightweight design
Illuminated RAPTR-1F reticle with 11 brightness levels
Aircraft-grade aluminum construction
State-of-the-art, fully multi-coated lenses with HD glass
Tool-free resettable turrets
Removable magnification lever
Waterproof, fog-proof, shockproof, and nitrogen-filled
Sunshade, magnification lever, and lens caps included


Eyepiece outer diameter: 46 mm
Magnification: 2 – 12x
Reticle: RAPTR-1F
Image plane: 2nd image plane
Mounting: None
Color: Black
Eyepiece diameter: 40 mm
Diopter adjustment: Yes
Parallax adjustment: Fixed at 100 yd
Objective outer diameter: 49 mm
1 click: 1/4 MOA
Illumination setting: 11 levels
Main tube diameter: 30 mm
Objective diameter: 42 mm
Linear field of view: 21 – 3.5 m @ 100 m
Exit pupil: 3.5 – 9.5 mm
Eye relief: 97 mm
Elevation adjustment range: 135 MOA
Windage adjustment range: 135 MOA
Weight: 640 g
Dimensions: 320x70x50 mm

Last image: Sample photo – riflescope mounted on a Bergara BA13 TD
