Pixfra thermal imaging monocular Arc A635P LRF

Pixfra Arc A635P LRF – Thermal Imaging Device with 1000 m Rangefinder

The Pixfra Arc A635P LRF is a compact thermal imaging monocular with an integrated laser rangefinder, specifically designed for hunting at medium distances. The powerful VOx sensor with 640x512 pixels, a 35 mm lens, and intuitive operation make it a reliable tool for night and forest hunting.

Strong Range & High-Resolution Sensor
With the bright 35 mm f1.0 lens, the Arc A635P achieves a detection range of up to 1800 meters. The thermal imaging sensor with a 12 µm pixel pitch delivers detailed images even in poor weather conditions with a NETD of under 20 mK.

Precise Rangefinder
The invisibly integrated laser rangefinder reliably measures distances up to 1000 m. Users can flexibly choose between single measurement and continuous measurement – ideal for quick decisions while stalking or during night hunting.

Optimized Image Quality Thanks to PIPS 2.0
The PIPS 2.0 image processing automatically enhances image details – through edge sharpening, zoom adjustment, and noise reduction. Six color palettes and hotspot tracking assist in quickly identifying heat sources.

Long Battery Life & Robust Housing
With two interchangeable batteries (each with approx. 6 hours of runtime), the device remains operational even during longer hunting sessions. The magnesium housing with IP67 certification reliably protects against dust, water, and harsh operating conditions.

Wi-Fi & Storage
Thanks to the integrated Wi-Fi, recordings can be streamed live to up to four mobile devices. The 32 GB internal storage offers space for numerous images and videos directly from the field.

Technical Specifications of the Pixfra Arc A635P LRF

Thermal Imaging Sensor: 640x512 pixels, VOx, 12 µm pitch, < 20 mK NETD
35 mm f1.0 lens with 1800 m detection range
Laser Rangefinder: 5 to 1000 m
OLED Display: 1440 x 1080 pixels
Digital Zoom: 2x / 4x / 8x
PIPS 2.0 firmware with image optimization
Field of View: 21.9 m at 100 m (horizontal)
6 color palettes & hotspot tracking
Magnesium alloy, IP67 certified – dust and waterproof
32 GB internal storage
Wi-Fi streaming to up to 4 devices
2x rechargeable battery with approx. 6 hours of runtime each
Dimensions: 172 x 53 x 78 mm
Weight: approx. 375 g
Operating Temperature: -30 °C to +55 °C

Scope of Delivery

Pixfra Arc A635P LRF thermal imaging device
2 batteries
Carrying strap
Protective case
Hand strap
USB-C charging cable
User manual
