GUIDE TE211 thermal imaging handheld device

Compact Thermal Imaging Monocular for Night Vision and Outdoor Use – Guide TE211
Powerful Thermal Imaging Technology in Pocket Size
The Guide TE211 is an ultra-lightweight and portable thermal imaging monocular that offers exceptional performance at an affordable price. With its compact design, it fits in any pocket and is ideal for outdoor adventures, hunting, or security applications.
Highly Sensitive 12μm Thermal Imaging Sensor
Thanks to the powerful 256 × 192 pixel sensor with 12μm pixel size and a NETD sensitivity of <30 mK, the TE211 enables detailed detection of even the smallest temperature differences. The 10mm lens provides clear and precise thermal images at short and medium distances.
High-Resolution AMOLED Display
The 800 × 600 AMOLED display delivers sharp, uniform, and high-contrast images. The comfortable eyepiece with 25mm eye relief reduces eye strain and provides a pleasant viewing experience.
18x Digital Zoom for Flexible Observations
With the 18x digital zoom, objects can be flexibly zoomed in on to see them more clearly from a distance. The various color modes optimally adjust the display to the lighting conditions.
Fast charging function for uninterrupted use
The integrated battery offers a runtime of up to 6 hours. Thanks to the 20W fast charging function, a 10-minute charge is sufficient for 1 hour of use, providing maximum flexibility.
Intuitive operation with just one button
The TE series relies on a user-friendly control concept: With just one button and a rotary knob, all functions can be easily controlled – ideal for quick use.
Integrated Photos, Videos, and Audio Recorder
The TE211 features a 16 GB storage capacity for photos, videos, and audio recordings, allowing special moments to be captured and accessed at any time.
Dual-Band WiFi for Real-Time Transmission
With the dual-band WiFi connection, the TE211 offers faster transmission speeds and a greater range. Upgrade packages can be downloaded in just 10 seconds, while the maximum transmission distance is 26.5 meters.
Technical Specifications

Property
Details


Sensor
256 × 192 infrared sensor


Pixel Size
12 µm


Frame Rate
50 Hz


Spectral Range
8–14 µm


NETD
< 30 mK


Display
800 × 600 AMOLED


Lens
10 mm


Field of View
31 × 23° at 100 m


Digital Zoom
18x


Laser Rangefinder
No


WiFi & App
Yes, Dual-Band WiFi


Battery Life
Up to 6 hours


Battery Type
Integrated rechargeable battery


Weight
248 g


Included Accessories
USB-C cable, hand strap, lens cover, eye mask, quick guide, safety information, warranty card
